Datacom DmSwitch 2000 Series User Manual

Chapter 1. Introduction
The front panel of the DmSwitch 3000F2 contains 24 10BASE-T/100BASE-TX ports, 4
10/100/1000Base-T/SFP combo ports, an RS-232 console port, an alarm port and two buttons for
changing stacking options.
Figure 1-7. DmSwitch 3000 F2 Front Panel
The front panel of the DmSwitch 3000F3 contains 24 100BASE-FX SFP ports, 4 10/100/1000Base-T/SFP
combo ports, an RS-232 console port, an alarm port and two buttons for changing stacking options.
Figure 1-8. DmSwitch 3000 F3 Front Panel
1.2.2. System Status LEDs
The System Status LEDs on the front panel can be used to monitor system activity. Following Figure
shows where the leds are located and the next table indicates the system status acording to each led’s
condition.
Figure 1-9. DmSwitch 3000 System LEDs Location
4

Datacom DmSwitch 2000 Series Specifications

General

Brand	Datacom
Model	DmSwitch 2000 Series
Category	Switch
Language	English
