Chapter 1. Introduction
Warning
Use only a DATACOM DmSwitch 3000 RPU to guarantee that only the main power
unit suplies power to the system when both main AC suply and RPU are connected
at the same time!
1.3.2. DmSwitch F2/G1 Rear Panel
The DmSwitch 3000F2 and DmSwitch 2000G1 Rear Panels contain two AC/DC power connectors and
two sites for Datacom Redundant Hot Swap Power Units.
Figure 1-14. DmSwitch F2 Rear Panel
The AC/DC power inputs accept any suply voltage in the range from 100~240 VAC at 50~60 Hz and
36~72VDC. Each connector suplies one Power Unit. The use of a redundant power unit is optional. The
switch is able to operate with a single unit.
1.3.3. DmSwitch F3 Rear Panel
The DmSwitch F3 Rear Panel contains two AC/DC power connectors and two sites for Datacom Redun-
dant Hot Swap Power Units.
Figure 1-15. DmSwitch F3 Rear Panel
9
