DKG-319 User Manual V-27
(14.04.2011)
- 6 -
Term Function
Technical data Description
21 EMERGENCY STOP
Digital inputs These inputs have programmable
characteristics selected via the program
menu. Each input may be driven by a
‘normally closed’ or ‘normally open’ contact,
switching either battery+ or battery-. The effect
of the switch is also selectable from a list. See
PROGRAMMING section for more details.
22 SPARE-2
23 PROGRAM LOCK
24 SPARE-1
25 COOLANT LEVEL
26 HIGH TEMP
27 LOW OIL PRESSURE
28 RECTIFIER FAIL
29 CURR_1+
Current transformer
inputs, 5A-AC
Connect the generator current transformer
terminals to these inputs. Do not connect the
same current transformer to other instruments
otherwise a unit fault will occur. Connect each
terminal of the transformer to the unit’s related
terminal. Do not use common terminals. Do
not use grounding. Correct polarity of
connection is vital. If the measured power is
negative, then change the polarity of each 3
current transformers. The rating of the
transformers should be the same for each of
the 3 phases. The secondary winding rating
shall be 5 Amperes. (For ex. 200/5 Amps).
30 CURR_1-
31 CURR_2+
32 CURR_2-
33 CURR_3+
34 CURR_3-
35 -
36 MAGNETIC PICKUP
Inputs, 1-30V
0-8KHz
Connect the magnetic pickup signal to these
inputs.
37 MAGNETIC PICKUP
To Next Page
