Datalogic BC9030 User Manual

BC9030-BT-BP Configuration
6 BC 9xx0-BT Cradle
RS-232
USB
BC9030-BT-BP Configuration
The BC9030-BT-BP configuration can be performed in three ways: by using
the Datalogic Aladdin
™
software configuration program, by sending configura-
tion strings from the Host PC via the RS-232 or USB-COM interface or by
reading configuration bar codes with the PowerScan™ PM9500 reader.
Datalogic Aladdin™
Datalogic Aladdin
™
is a multi-platform utility program that provides a quick
and user-friendly configuration method via the RS-232/USB-COM interface.
It also allows upgrading the software of the connected device (see the Data-
logic Aladdin
™
Help On-Line for more details).
NOTE
The power supply is required only if you need to connect the interface
cable to a standard USB Port. The power supply is not required if you
connect the interface cable to a PoweredUSB 12V or 24V port.

Datalogic BC9030 Specifications

General

Compatibility	Datalogic handheld scanners
Power Supply	External power supply
Mounting Options	Desk/Wall mounting
Type	Charging cradle
Connectivity Technology	Cable
Host Interface	USB
Interface	USB
Operating Temperature	0 to 40 °C (32 to 104 °F)
Storage Temperature	-20 to 70 °C (-4 to 158 °F)
Humidity	5% to 95% non-condensing
Charging	Cradle/Charger
