Datalogic BC9030 User Manual

Installation
2 BC 9xx0-BT Cradle
Installation
To set up your BC9030-BT-BP cradle you must:
1. Physically install the cradle.
2. Make all system connections.
3. Configure the BC9030-BT-BP cradle.
The cradle package contains the following items:
Regulating the Cradle Position
To regulate the position, use the hex key to unscrew the holder and slide it to
the desired position.
• BC9030 BT Presentation Base • Hex Key
• BC9030-BT-BP Quick Reference Guide
(this manual)
• Rubber Spacers
• Metal Mounting Plate

Datalogic BC9030 Specifications

General

Compatibility	Datalogic handheld scanners
Power Supply	External power supply
Mounting Options	Desk/Wall mounting
Type	Charging cradle
Connectivity Technology	Cable
Host Interface	USB
Interface	USB
Operating Temperature	0 to 40 °C (32 to 104 °F)
Storage Temperature	-20 to 70 °C (-4 to 158 °F)
Humidity	5% to 95% non-condensing
Charging	Cradle/Charger
