Installation
4 BC 9xx0-BT Cradle
Mounting with the Metal Plate
1. Affix the metal plate onto the desired mounting surface using the
two center screw holes (see Figure 1 on page 4).
2. Slide the tabs on the back of the cradle onto the metal plate as
shown in Figure 1.
3. After aligning the tabs, push up to lock into place.
Figure 1. Mounting Plate on Wall

Datalogic BC9030 Specifications

General

Compatibility	Datalogic handheld scanners
Power Supply	External power supply
Mounting Options	Desk/Wall mounting
Type	Charging cradle
Connectivity Technology	Cable
Host Interface	USB
Interface	USB
Operating Temperature	0 to 40 °C (32 to 104 °F)
Storage Temperature	-20 to 70 °C (-4 to 158 °F)
Humidity	5% to 95% non-condensing
Charging	Cradle/Charger
