Datalogic BC9030 User Manual

Technical Features
Quick Reference Guide 19
* Having a switching regulator inside, the BC9030-BT-BP draws the same
power, regardless of the supply voltage. i.e. as the input voltage increases
the current drawn decreases
MECHANICAL FEATURES
Weight without metal plate 490gr
Dimensions (without antenna)
WHEN HORIZONTALLY POSITIONED:
Height 125mm
Length 215mm
Width 98mm
WHEN VERTICALLY POSITIONED:
Height 185mm
Length 85mm
Width 98mm
SYSTEM CONFIGURATION
Max number of devices per base
station
7

Datalogic BC9030 Specifications

General

Compatibility	Datalogic handheld scanners
Power Supply	External power supply
Mounting Options	Desk/Wall mounting
Type	Charging cradle
Connectivity Technology	Cable
Host Interface	USB
Interface	USB
Operating Temperature	0 to 40 °C (32 to 104 °F)
Storage Temperature	-20 to 70 °C (-4 to 158 °F)
Humidity	5% to 95% non-condensing
Charging	Cradle/Charger
