Quick Reference Guide 35
Connections
USB Connection
USB Direct Connection
You can use the supplied USB charge/communication cable to
directly connect the DL-Axist to a host computer and transfer data
through the USB interface.
USB Dock Connection
The single dock can be connected to the host computer by means of
a standard micro USB cable.
Once the host computer has been turned on, insert the DL-Axist into
the dock.
NOTE
Connection through the cable complies to USB 2.0
standard.
Host
Computer
DL-Axist
USB cable
Host
Computer
DL-Axist
USB cable
Single Slot
Dock
Power Supply
