DATALOGIC
12
TECHNICAL FEATURES
Electrical Features
Battery Type 2 AA NiMh* batteries
Time of recharge NiMh 2 hours
Operating autonomy
(typ. continuous reading)
60,000 reads - NiMh
Display
(Only available with some models)
LCD 4 lines x 16 chars
Programmable font and backlight
Indicators Laser On / battery low LED (red)
Programmable Beeper
Laser Features
Standard LR
Power (typical) in mW 0.9 mW 1.4 mW
Light Source VLD in the range between 630~680 nm
Scan rate 35 ± 5 scans/sec
Typical reading field width see reading diagram
Max. resolution 0.12 mm, 5 mils 0.25 mm, 10 mils
PCS minimum
(Datalogic Test Chart)
15% 40%
Scan angle 42° 23°
Laser Safety Class 2 (EN 60825-1 / CDRH)
Radio Features
European Models USA Models
Working frequency 433.92 MHz 910 MHz
Bit rate 19200 baud 36800 baud
Range (in open air) 50 m. 30 m.
System Configuration OM-DRAGON™ STARGATE™
Max. number of devices
per base station
32 255
Max. number of devices
in the same reading area
2000
Environmental Features
Working Temperature
-10 to + 40 °C / +14 to +104 °F
Storage Temperature
-20 to + 50 °C / -4 to +140 °F
Humidity 90% non condensing
Drop resistance (on concrete)
with display
without display
1.5 m
1.8 m
Protection sealed against rain and dust
Mechanical Features
Weight (with batteries) about 340 g.
Dimensions 203 x 117 x 69 mm
Material ABS and Polycarbonate molded with rubber
* It is possible to employ also NiCd or non-chargeable Alkaline AA batteries.
