DS2 Ethernet Instruction Manual
42
10. TECHNICAL DATA
DS2-05-07-xxx-JE
Power supply:
24 Vcc  20%
Consumption of emitter unit:
250 mA max without load
Outputs:
1 switching output: load max 10 k
load min 100 
1 analogue output : 0-10 V (V
max.
2%)
Output current on switching output:
100 mA; short-circuit protection
Output voltage on switching output:
-1.5 Vmax of the power supply at T=25°C
Response time:
See table “Response time” below
Emission type:
Infrared (880 nm)
Resolution:
12 mm
Relative measurement precision:
 6 mm
Absolute measurement precision:
6 mm
Dimensional difference between objects
equally detected in asbolute Teach-in:
 6 mm
Dimensional difference between objects
equally detected in relative Teach-in
 = 12 mm
Operating distance:
0.3 ÷ 5 m
Available functions:
See previous sections
Operating temperature:
0…+ 50 °C
Storage temperature:
- 25…+ 55 °C
Electrical protection:
Class I
Mechanical protection:
IP65 (EN 60529)
Vibrations:
0.5 mm width, 10 … 55 Hz frequency (EN 60068-2-6)
Shock resistance:
11 ms (30 G) 6 shock for each axis (EN 60068-2-27)
Housing material:
Painted aluminium (Pulverit 5121/0085 Black)
Lens material:
PMMA
Connections:
M12 4-poles connector for TX
M12 8-poles and M12 4-poles type “D” connector for RX
Weight:
min 3.3 Kg – max 6.5 Kg (with packing)
10.1. Response time
Model
Configuration
Top Beam
Complete Beams Status
binary
ASCII
binary
ASCII
DS2-05-07-060-JE
10
10
10
12
DS2-05-07-075-JE
11.5
11.5
11.5
15
DS2-05-07-090-JE
13
13
13
17
DS2-05-07-120-JE
17
17
17
21
DS2-05-07-150-JE
20
21
21
25
DS2-05-07-165-JE
22
23
23
28
