Datalogic DS4600A Quick Reference Guide

DS4600A QUICK GUIDE
Connectivity:
Point-to-point layout
c Main Serial Interface
dAuxiliary Serial Interface (Local Echo) (RS232)
eExternal Trigger (for On-Line Mode)
Pass-through layout Multiplexer layout
c Main Serial Interface (RS232) c Main Serial Interface (RS485 Half-Duplex)
dAuxiliary Serial Interface (RS232) dAuxiliary Serial Interface (Local Echo) (RS232)
eExternal Trigger (for On-Line Mode) eExternal Trigger (for On-Line Mode)
RS232 Master/slave layout RS485 Master/slave layout
c Main Serial Interface (Slaves RS232 only) c Auxiliary Serial Interface (RS232)
dAuxiliary Serial Interface (RS232) d Main Serial Interface (RS485 Half-Duplex)
eExternal Trigger (for On-Line Mode) eExternal Trigger
