Datalogic DS6300

DS6300 DEVICENET
18
SOFTWARE FEATURES ENVIRONMENTAL FEATURES
Readable Codes
Interleaved 2/5
Operating
0° to +40 °C (+32 to +104 °F)
Code 39 standard
Temperature
Codabar
Storage
-20° to +70 °C (-4° to +158 °F)
Code 128
Temperature
EAN 128
Humidity
90% non condensing
Code 93 (standard & full ASCII)
Vibration
IEC 68-2-6 test FC
EAN/UPC
Resistance
1.5 mm; 10 to 55 Hz
Code Selection
Up to 10 codes during one 2 hours on each axis
reading phase
Shock Resistance
IEC 68-2-27 test EA
Headers and
Up to 128-byte headers and 30 G; 11 ms
Terminators
128-byte terminators 3 shocks on each axis
Protection Class
IP64
Operating Modes
On Line, Automatic, Test,
PHYSICAL FEATURES
Config. Mode
Genius™ utility program
Std Models Oscill. Mirror
Dimensions mm
(inch)
110x113x99
(4.33x4.45x3.9)
113x180x104.5
(4.45x7.08x4.11)
Parameter Storage
Non-volatile internal FLASH
Weight
1.5 kg (3.3 lb) 2.0 kg (4.4 lb)
Accessories:
Name Description Part Number
CAB-6011 Cable to C-BOX100 1 m 93A051221
CAB-6012 Cable to C-BOX100 2 m 93A051222
CAB-6015 Cable to C-BOX100 5 m 93A051223
C-BOX 100 Passive connection box 93ACC1510
INT-30 20 mA C.L. interface board for C-BOX 100 93A151022
GFC-60 90° mirror 93A201100
GFC-600 90° mirror close distance 93A201102
GFX-60 X-pattern mirror 93ACC1730
PWR-120 Power unit 110/230 V AC - 24 V DC 93ACC1530
BTK-6000 Terminator kit (5 pcs) 93ACC1710
PG6002 Single unit power supply – US 93ACC1718
PG6001 Single unit power supply – UK 93ACC1719
PG6000 Single unit power supply – EU 93ACC1720
FBK-6000 Fast bracket kit (2 pcs) 93ACC1721
US-60 Mounting bracket kit (5 pcs) for multisided stations 93ACC1729
MEP-542 Photocell kit – PNP 93ACC1727
MEP-543 Photocell kit – NPN 93ACC1728
Electrical Connections:
The DS6300 DeviceNet reader provides a 26-pin male D-sub connector for connection to power supply and
input/output signals.
A DeviceNet connector is used for connection to the remote Host, while a local Lonworks 9-pin female connector
connects the DeviceNet master to the first slave reader of the system.
NOTE
When using DeviceNet, the Main serial interface is disabled and must not be physically
connected.
