Product Reference Guide 121
Gryphon D432/D412 Plus™
* Reading distances are measured from the nose of the reader.
NOTE: Typical performance at 20ºC / 68ºF on high quality barcodes.
Optical Features
Focus distance 140 mm
Field of view 28° (H) x 23° (V)
Horizontal field of view at distance (d) in
mm
0.52d + 15
Vertical field of view at distance (d) in mm 0.42d + 12
Max Resolution
Linear codes -
mm (mils)
PDF 417 – mm
(mils)
Datamatrix – mm
(mils)
0.10 (4 mils) 0.10 (4 mils) 0.17 (6.6 mils)
Depth of field*
1D (linear):
X-dimension
mm (mils)
DOF
cm (in)
Code39 0.13 (5)
7.5 to 15.5
(2.95 to 6.10)
0.5 (20)
5.5 to 36.5
(2.17 to 14.37)
EAN13 0.33 (13)
5.0 to 27
(1.97 to 10.63)
2D:
X-dimension
mm (mils)
DOF
cm (in)
PDF417 0.13 (5)
8.0 to 18.5
(3.15 to 7.28)
0.25 (10)
4.0 to 25.5
(1.57 to 10.04)
QR 0.19 (7.5)
8.0 to 16.5
(3.15 to 6.5)
0.25 (10)
7.0 to 19.5
(2.76 to 7.68)
DataMatrix 0.19 (7.5)
8.0 to 16.5
(3.15 to 6.5)
0.25 (10)
7.0 to 19.5
(2.76 to 7.68)
Skew ±40°
Pitch ±35°
Rotation 360°
Print Contrast (Min.) 15%
