Datalogic Gryphon GM4102 User Manual

Quick Reference Guide i
Table of Contents
Software Product Policy ............................................................. vii
Customers Under Software Support ................................ vii
Setting Up the Reader .................................................................. 1
Configure the Base Station ......................................................... 1
Changing the Base Station Position .................................. 2
Connecting the Base Station ..............................................4
Securing the DC Power Cord (Optional) .................... 5
Using the BC40xx™ Radio Base .................................................... 7
Base LEDs ............................................................................. 7
Charging the Batteries ................................................................. 8
Battery Safety ...................................................................... 8
Replacing the Batteries ..................................................... 11
Linking the Reader to a Base Station .......................................13
RF Devices ..........................................................................13
System and Network Layouts ...................................................13
Stand Alone Layouts .......................................................... 13
Select the Interface Type ............................................................ 15
Interface Selection ............................................................. 15
Configuring the Interface ..................................................15
Keyboard Interface ...................................................................... 21
Standard Factory Settings ................................................21
Scancode Tables .................................................................21
Country Mode .............................................................................. 21
Caps Lock State ........................................................................... 26
Numlock ....................................................................................... 27
Programming ...............................................................................27
Using the Programming Barcodes ................................... 28
Configure Other Settings ......................................... 28
Resetting Standard Product Defaults .................... 28
Technical Specifications ............................................................. 29
LED and Beeper Indications ....................................................... 32
Error Codes ..................................................................................34
Base Station Indications ............................................................35
Ergonomic Recommendations ..................................................36
Cleaning Procedure ..................................................................... 37
Common Cleaning Solutions ............................................. 37
Cleaning enclosure and window surfaces ....................... 38
Cleaning electrical contact surfaces ................................38
Datalogic Limited Factory Warranty ................................39
Warranty Coverage ................................................... 39
Warranty Claims Process......................................... 39

Datalogic Gryphon GM4102 Specifications

General

Type	Handheld bar code reader
Sensor type	-
Scanner type	1D
Read rate (max)	325 reads/s
Tilt reading angle	-35 - 35 °
Pitch reading angle	-65 - 65 °
Sustainability certificates	RoHS
Charging time	4 h
Battery capacity	2100 mAh
Power source type	Battery
Number of reads per charge	50000
Wireless range	15 m
Operating frequency	910 MHz
Standard interfaces	RF Wireless
Product color	Green, White
International Protection (IP) code	IP52
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %
Harmonized System (HS) code	84716070

Weight and Dimensions

Depth	100 mm
Width	71 mm
Height	181 mm
Weight	246 g
