Technical Features
Quick Reference Guide 23
Technical Features
Item Description
Physical Characteristics
Color
White/Grey
Black/Grey
Dimensions
Height 7.1” / 181mm
Length 3.9” / 100mm
Width 2.8” / 71mm
Weight (without
cable)
Approximately 6.3 ounces/180 g
Electrical Characteristics
Voltage & Current
Input current at 5V = 460 mA (max)
2.5 mA (RS-232 sleep mode)
2.5 mA (USB suspend)
Input Power = 2.42W max in the 5V±5% range
Performance Characteristics
Light Source
Dual LEDs
Tilt (Roll)
Tolerance
± 35° from normal
Pitch (Yaw)
Tolerance
± 65°
Skew Tolerance
± 65°
Field of View
10.0” (25.4cm) wide at 12.5” (31.8cm) from the
reader
Depth of Field
(Typical)
3 mil – 2.9” to 4.7” (7.5cm to 12cm)
13 mil
*
– 1.2” to 23.6” (3cm to 60cm)
20 mil – 1.2” to 31.5” (3cm to 80cm)
Minimum
Element Width
3 mil
Print Contrast
Minimum
15% minimum reflectance
