LED and Beeper Indications
Quick Reference Guide 25
LED and Beeper Indications
The imager’s beeper sounds and its LED illuminates to
indicate various functions or errors on the reader. A
“Green Spot” also lights to indicate a good read. The tables
below list these indications. One exception to the behav-
iors listed in the tables is that the reader’s functions are
programmable, and may or may not be turned on. For
example, certain indications, such as the power-up beep
can be disabled using programming barcode labels. Refer-
ence the PRG for a more detailed list.
Indication LED Beeper
Power-up
LED flashes/blinks
on power-up, how-
ever, this may be too
rapid to view. With a
USB interface, the
LED blinks until enu-
meration with the
host is completed.
Imager beeps four
times at highest fre-
quency and volume
upon power-up.
Good Read
LED behavior for this
indication is configu-
rable using the PRG.
One beep at current
frequency, volume,
mono/bi-tonal setting
upon a successful
label scan.
ROM Failure
200ms on / 200ms
off
Imager sounds one
error beep at highest
volume for 200 mS.
Limited
Scanning
Label Read
N/A
Imager 'chirps' six
times at the highest
frequency and current
volume.
Imager Dis-
abled
The LED blinks con-
tinuously 100mS on
/ 900 mS off
N/A
