GRYPHON™ MX00
7
TECHNICAL FEATURES
Gryphon™ Mx00
Electrical Features
Battery Type 2 AA NiMh* batteries
1.2 V – 1400 mAh
Time of recharge NiMh 3.5 hours
Operating autonomy
(typ. continuous reading)
25,000 reads - NiMh
Indicators LED, Good Read Spot, Beeper
Max scan rate 270 scans/sec
Optical Features
Sensor CCD solid state (3648 pixels)
Illuminator LED array
Wavelength 630 ~ 670 nm
Max. LED Output Power 0.33 mW
Reading field see reading diagram
Max. resolution 0.076 mm, 3 mils
PCS minimum 15% (Datalogic Test Chart)
Radio Features
European Models USA Models
Working frequency 433.92 MHz 910 MHz
Bit rate 19200 baud 36800 baud
Effective Radiated Power <10 mW < 1mW
Range (in open air) 30 m 15 m
RF Modulation FSK
System Configuration OM-GRYPHON™ STARGATE™
Maximum number of devices per
base stations
16 255
Max. number of devices in the
same reading area
2000
Environmental Features
Working Temperature 32° to 104 °F
Storage Temperature
(without battery)
- 4° to 158 °F
Humidity 90% non condensing
Drop resistance IEC 68-2-32 Test ED
Protection class IP30
Mechanical Features
Weight (with batteries) about 9.87 oz
Dimensions 7.04 x 3.18 x 3.85 in
Material ABS and Polycarbonate molded with
rubber
* It is possible to employ also NiCd or non-chargeable Alkaline AA batteries.
