Symbologies Enter/Exit Programming Mode

Product Reference Guide

213

BC412 Decoding Level

Decoding Levels are used to configure a bar code symbology decoder to be very

aggressive to very conservative depending on a particular customer’s needs.

See "Decoding Levels" on page 245 for more detailed programming instruc-

tions.

BC412 Decoding Level = Disable

BC412 Decoding Level = 1

BC412 Decoding Level = 2

BC412 Decoding Level = 3

DEFAULT

BC412 Decoding Level = 4

BC412 Decoding Level = 5

$CBCDL00

$CBCDL01

$CBCDL02

$CBCDL03

$CBCDL04

$CBCDL05

Default Chapter3
