Datalogic Magellan 800i Quick Reference Guide

2Magellan
TM
800i
The Magellan 800i utilizes illumix™ intelligent illumination technol-
ogy to optimize light levels for a variety of bar code scanner func-
tions including automatic reading of bar codes from printed
surfaces, mobile devices and image capture in variable contrast
environments.
Mounting the Scanner (Optional)
The scanner can be permanently attached to a wall or countertop
as follows:
1. After identifying an optimal position for the scanner, cut
out and securely hold the screw hole template (located on
the inside back cover) in the desired position matching the
scanner’s footprint.
2. Mark the center of both screw locations using a pencil or
marker and remove the template.
3. If necessary, drill pilot holes in the marked positions, then
thread two pan head
1
, self-tapping screws in place, leav-
ing their heads protruding approximately 1/8” (3mm)
above the counter or wall surface.
4. Align the larger ends of the keyholes located on the scan-
ner’s bottom with the protruding screw heads, then push
down and rotate clockwise to lock the scanner in position.
1. The screw heads must fit inside the larger end of the keyholes on the
bottom of the scanner.

Datalogic Magellan 800i Specifications

General

Scanner type	2D
Yaw reading angle	-60 - 60 °
Decoding standards	GS1 DataBar, Aztec Code, Data Matrix, MaxiCode, QR Code, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, MicroPDF417, PDF417
Tilt reading angle	0 - 360 °
Optical sensor resolution	752 pixels
Light levels (direct sunlight)	0 - 86000 lx
Bluetooth	No
Cable length	2 m
Standard interfaces	USB
Input voltage	5 V
Power consumption	350 mA
Dimensions (WxDxH)	76 x 109 x 151 mm
Certification	China RoHS EU RoHS
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	306.2 g
