Volume/Tone Push Button
The Volume/Tone Push Button also performs multiple functions depend-
ing upon the duration of time it is pressed:
Table 2. Volume/Tone Push Button Functions
PRESS
DURATION
FUNCTION COMMENT
Momentary (when
scanner is in Sleep
Mode)
Wakes scanner from
Sleep Mode
Alternatively, the scanner can be awakened by:
- Moving an object through the scan zone.
- A weight change on the scale.
- Scanning with an attached auxiliary scanner.
Momentary (when
scanner is in Normal
Operating Mode)
Increments volume
Press the push button momentarily to increase speaker vol-
ume. When the loudest volume is reached, a repeated press
of the push button cycles volume back to the lowest setting,
then volume increases on subsequent press(es). Four vol-
ume levels are available.
Hold, then release
when the beeper
sounds
Increments tone
Press the push button for approximately 2 seconds, then
release. Each time this is done, the beeper will sound at one
of three tones. Stop when the desired tone (high, medium or
low) is sounded.
4 Seconds
Scanner Diagnostics
Mode
a
This mode allows system support personnel to troubleshoot
problems with the scanner. Generally diagnostics are initiated
after noting a Field Replaceable Unit (FRU) Warning (see
Tabl e 1 ). Cycle power to exit Scanner Diagnostics Mode.
8 Seconds
Resets Scanner
b
Only system support personnel should perform a reset.
a. By standard default, this function is normally disabled to prevent accidental activation by users.
b. Users should not perform scanner resets except under the direction of trained systems support person-
nel.
