Quick Reference Guide 1
Quick Reference
The object of this manual is to provide general operational information for the
user. For more product details, including installation, set-up, programming and
advanced user information, reference the Product Reference Guide (PRG), which
is available for viewing and download from the website listed on the back cover of
this manual.
Controls and Indicators
The control panel consists of an indicator LED and two push buttons as shown in
Figure 1. The bottom-most button also serves as an indicator LED for scale func-
tions (scale models ONLY). The unit also includes a speaker (beeper) which can
be configured to sound indications of scanning and weighing activities. Refer to
LED and Beeper Indications for more information about the functions of the push
buttons and indicators.
Figure 1. Controls and Indicators
