Datalogic Magellan 9400i Quick Reference Guide

8 Magellan
TM
9300i and 9400i
Error Codes
Upon startup, if the scanner sounds a long error tone followed by alternating flashing of
the green and yellow LED indicators, and an error code is displayed on the Health & Sta-
tus Indicator, this means the scanner has not passed its automatic Selftest and has
entered
FRU (
Field Replaceable Unit) isolation mode. The scanner remains in this mode,
until any button is pushed.
After a button is pushed, the scanner flashes the green LED a set number of times to
indica
te the error code. After one cycle of flashing has passed, another button push
resets the scanner. The Product Reference Guide (PRG) describes the LED flash codes
associated with an error found. If your scanner indicates any of these errors, note the
code number, then contact Helpdesk for assistance.
ScaleSentry
TM
Indications
Flashing Red = ScaleSentry beam blocked.
Off = ScaleSentry beam is not blocked
Sensormatic® EAS Indications
If the scanner is equipped with the optional Sensormatic EAS opton, various deactivation
and validation indications will be enabled.
INDICATION EAS LED
BEEPER
COMMENT
Count Frequency Volume Duration
Entering EAS
Coupled Mode
Green ON N/A
Upon sensing an inac-
tive to active transi-
tion
Red ON
Green OFF
N/A While in EAS Coupled Mode.
Upon sensing an active
t
o
inactive transition
Red OFF
Green ON
N/A While in EAS Coupled Mode.
Upon receiving
validation of EAS tag
deactivatio
n
Ora
nge ON until
EAS b
e
eper
turns OFF
1 ~ 1500 Hz Current Configurable While in EAS Coupled Mode.
EAS Bad Beep N/A Same as FRU error tone While in EAS Coupled Mode.
Label Programming Mode Indications
These indications occur only when the scanner is in Programming Mode or when placing
the scanner in that mode.
INDICATION LED BEEP(S)
Label Programming Mode Entry
Continuous blink 1 sec. ON
/ 1 sec. OFF
Same as good read indication
Acceptance of Partial Labels
N/A 1
Partial Label Reading Cancel
N/A 6
Acceptance of Complete Labels
N/A 3

Datalogic Magellan 9400i Specifications

General

Standard interfaces	USB
Connectivity technology	Wired
Type	Built-in bar code reader
Sensor type	Linear
Scanner type	1D/2D
Light levels (direct sunlight)	0 - 86080 lx
Linear (1D) barcodes supported	GS1 DataBar Expanded, GS1 DataBar Omnidirectional, JAN, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Data Matrix, Micro QR Code, QR Code, Small Aztec Code
Input voltage	100 - 240 V
Input frequency	50 - 60 Hz
Power source type	AC
Power consumption (standby)	11 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 40 °C
Operating relative humidity (H-H)	5 - 95 %
Product color	Black, Grey
Housing material	-
Sustainability certificates	RoHS

Weight and Dimensions

Depth	102 mm
Width	401 mm
Height	130 mm
Weight	- g
