Datalogic Magellan CSS4400 User Manual

Technical Features
Quick Reference Guide 11
Item Description
Performance Characteristics
Nominal Frame Rate 53 frames/second
Light Source Dual Red LEDs
Roll (Tilt) Tolerance Up to ± 180°
Pitch Tolerance ± 40°
Skew (Yaw) Tolerance ± 40°
Print Contrast Minimum 25% minimum reflectance
Field of View 40° H x 26° V
Depth of Field (Typical)
cm inches
NF FF NF FF
Code 39 5mil
Code 39 10mil
Code 39 20mil
4.7
1.7
1.1
17.7
33.2
492
1.8
0.7
0.4
7.0
13.1
19.4
EAN 7.5mil
EAN 13mil
2.8
2.5
27.3
41.9
1.1
1.0
10.8
16.5
PDF-417 6.6mil
PDF-417 10mil
PDF-417 15mil
3.3
2.2
2.5
15.4
23.9
35.6
1.3
0.9
1.0
6.0
9.4
14.0
DataMatrix 10mil
DataMatrix 15mil
2.7
1.2
17.1
24.6
1.1
0.5
6.7
9.7
QR Code 10mil
QR Code 15mil
3.5
0.5
16.0
24.3
1.4
0.2
6.3
9.6
Minimum Element Width
1D Min Resolution = 4 mil
PDF-417 Min Resolution = 5 mil
Datamatrix Min Resolution= 7 mil
* 13 mils DOF based on EAN. All others are Code 39. All labels grade A, minimum
illumination 100 lux, 20°C, label inclination 10°, static reading.
