Mounting Bracket
Quick Reference Guide 5
Under Shelf Mount
If the CSS is to be mounted beneath a shelf, counter, or other hor-
izontal surface; the mounting plate can be carefully bent to the
necessary angle as shown in Figure 5.
Figure 5. Mounting Under a Shelf
Pole Mount
The Standard Mount will also permit the CSS to be secured to a
pole or post as demonstrated in Figure 6. Use the slots shown to
attach cable ties or other sturdy cord or line.
Figure 6. Mounting to a Pole or Post
