Error Mode
18 Customer Service Scanner
Figure 9. CSS Dimensions
39.04 mm
58 mm
45 mm
11.2 mm
M3 Inserts
(X4)
3.56 mm
7.8 mm
15.44 mm
25.5 mm
Scan Window Side Side View
Back Side
57.1 mm
19.8 mm
Read
Line
50.97 mm
