MATRIX 400™ QUICK GUIDE
16
TECHNICAL FEATURES
ELECTRICAL FEATURES
Power
Supply Voltage 10 to 30 Vdc
Power Consumption 8 W max.; 5 W typical
Communication Interfaces
Main
- RS232
- RS485 full-duplex
- RS485 half-duplex
Auxiliary - RS232
Ethernet (Ethernet Models only)
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
2400 to 115200 bit/s
10/100 Mbit/s
Inputs
External Trigger and IN2
Opto-coupled and polarity insensitive
Outputs
OUT1 and OUT2
Opto-coupled
OPTICAL FEATURES 400-4xx-xxx models 400-6xx-xxx models
Image Sensor CMOS CCD
Image Format SXGA (1280x1024) UXGA (1600x1200)
Frame Rate 27 frames/sec. 15 frames/sec.
Pitch
± 35°
Tilt 0° - 360°
Lighting System Internal or External Illuminator (accessories)
LED Safety Class Class 1 to EN60825-1
USER INTERFACE
LED Indicators Power, Ready, Good; Trigger; Com, Status, (Network); (Green Spot)
Keypad Button Configurable via VisiSet™
SOFTWARE FEATURES
Readable Code Symbologies
1-D and stacked 2-D POSTAL
• PDF417 Standard and Micro PDF417
• Code 128 (EAN 128)
• Data Matrix ECC 200
(Standard and Direct Marking)
• Australia Post
• Royal Mail 4 State Customer
• Code 39 (Standard and Full ASCII)
• Interleaved 2 of 5
• QR Code
(Standard and Direct Marking)
• Kix Code
• Japan Post
• Codabar • MAXICODE • PLANET
• Code 93 • Aztec Code • POSTNET, POSTNET (+BB)
• Pharmacode
• EAN-8/13 - UPC-A/E
(including Addon 2 and Addon 5)
• GS1 DataBar (RSS) Family
• Composite Symbologies
• Microglyph
(this symbology requires an
activation procedure – contact your
local Datalogic Automation
distributor for details)
• POSTNET + PLANET,
POSTNET (+BB) + PLANET
Operating Mode ONE SHOT, CONTINUOUS, PHASE MODE
Configuration Methods
By means of X-PRESS™ Human Machine Interface or VisiSet™ configuration
software
Parameter Storage Permanent memory (Flash)
CODE QUALITY VERIFICATION
Standard Supported Symbologies
ISO/IEC 16022 Data Matrix ECC 200
ISO/IEC 18004 QR Code
ISO/IEC 15415 Data Matrix ECC 200, QR Code
ISO/IEC 15416 Code 128, Code 39, Interleaved 2 of 5, Codabar, Code 93, EAN-8/13, UPC-A/E
AS9132A Data Matrix ECC 200
MECHANICAL FEATURES
Dimensions 123 x 60.5 x 87 mm (4.85 x 2.38 x 3.43 in.) with lens cover
Weight 482 g. (17 oz.) with lens and internal illuminator
Material Aluminium
ENVIRONMENTAL FEATURES
Operating Temperature
0 to 50 °C (32 to 122 °F)
Storage Temperature
-20 to 70 °C (-4 to 158 °F)
Max. Humidity 90% non condensing
Protection Class IP67
