Datalogic P2x-Series User Manual

ELECTRICAL CONNECTIONS
38 P2X-SERIES™
EXTERNAL TRIGGER INPUT CONNECTIONS USING EXTERNAL
POWER
Figure 5 - PNP External Trigger Using External Power
Figure 6 - NPN External Trigger Using External Power
CBX500/800 FUNCTION
+V
Power Source - Inputs
I2A
Input 2 + or - (polarity insensitive)
I2B
Input 2 + or - (polarity insensitive)
-V
Power Reference - Inputs
