SOFTWARE CONFIGURATION
50
P2X-SERIES™
• Chains Enabled for the 36 LEDs illuminator
Chain 1
Chain 2
Chain 3
Chain 4
Chain 5
Chain 6
The pictures below display the relative position on the illuminator.
Illuminator Vertical Position
Chain 4
Chain 5
Chain 6
Chain 1Chain 3
Chain 2
Illuminator Horizontal Position
Chain 1
Chain 2
Chain 3
Chain 4
Chain 5
Chain 6
