Lighting System
Internal Illuminator (14 or 36 LEDs) and External Strobe (Output 3)
ENVIRONMENTAL FEATURES
Operating Temperature
b
-10 to 50°C (14 to 122°F)
Storage Temperature
-20° to 70°C (-4 to 158°F)
Max. Humidity
90% non condensing
Vibration Resistance
EN 60068-2-6
14 mm @ 2 to 10 Hz; 1.5 mm @ 13 to 55 Hz;
2 g @ 70 to 500 Hz; 2 hours on each axis
Bump Resistance
EN 60068-2-29
30g; 6 ms;
5000 shocks on each axis
Shock Resistance
EN 60068-2-27
30g; 11 ms;
3 shocks on each axis
Protection Class
EN 60529
c
IP65/IP67
PHYSICAL
FEATURES
14 LEDS ILLUMINATOR 36 LEDS ILLUMINATOR
Dimensions
(with lens cover)
H x W x L
109 x 54 x 56 mm (4.3 x 2.1 x 2.2 in.)
H x W x L
116 x 126x70 mm (4.6 x 4.9 x 2.8 in.)
Weight about 380g. (13.4 oz.) about 640g. (22.5 oz.)
Material Aluminium
USER INTERFACE
LED Indicators Power, Busy/Trigger, Out 1; Out 2; Out 3, Online
Keypad Button Reset; Camera Button Event (internal software event only); Loader
HARDWARE FEATURES
Storage 380MB
RAM 1 GB
a. When connected to the CBX connection boxes the electrical features for Output 1 and 2 become the following:
V
CE
= 30 Vdc max.; I
CE
= 40 mA continuous max.; 130 mA pulsed max.; V
CE saturation
= 1 Vdc max. @ 10 mA; P
D
= 90 mW
Max. @ 50 °C ambient temp.
b
. Use metal mounting bracket for heat dissipation in high ambient temperatures.
c. When correctly connected to IP67 cables with seals.
ELECTRICAL FEATURES

Datalogic P2x-Series Specifications

General

Brand	Datalogic
Model	P2x-Series
Category	Digital Camera
Language	English
