PRODUCT REFERENCE GUIDE
63
LED (LIGHT EMITTING DIODE)
A low power electronic light source commonly used as an indicator light. It uses less
power than an incandescent light bulb but more than a Liquid Crystal Display (LCD).
LED ILLUMINATOR
LED technology used as an extended lighting source in which extra optics added to the
chip allow it to emit a complex radiated light pattern.
MATRIX SYMBOLOGIES (2D CODES)
An arrangement of regular polygon shaped cells where the center-to-center distance of
adjacent elements is uniform. Matrix symbols may include recognition patterns which
do not follow the same rules as the other elements within the symbol.
OCR
Means Optical Character Recognition. This technology allows to read and convert typed,
printed or handwritten characters into machine-encoded texts to be managed. Impact
Software offers a wide range of OCR tools, for more information see Impact Reference
Guide.
PATTERN RECOGNITION
The automated recognition process of patterns and regularities in data. The information
stored in a database is matched with the incoming data. Impact Software offers a wide
range of pattern tools, for more information see Impact Reference Guide.
RAM
Random Access Memory. Data in RAM can be accessed in random order, and quickly
written and read.
SHUTTER OPEN TIME (EXPOSURE TIME)
The time during which the image to be acquired is exposed to the camera's image sen-
sor.
TRANSMISSION CONTROL PROTOCOL/INTERNET PROTOCOL (TCP/IP)
A suite of standard network protocols. The TCP governs sequenced data; the IP governs
packet forwarding. TCP/IP is the primary protocol that defines the Internet.
VISION PROGRAM MANAGER (VPM)
The Impact software module that provides tools to configure the P2x-Series™ camera
and create vision programs for inspection and control.
Throughout this manual, the name “VPM” is used to refer to the software installed on
the camera.
