Technical Specifications

316

PowerScan™ PD953X/PBT950X/PM950X

Table 53.

Standard Cable Pinouts

Pin RS-232 USB Keyboard Wedge

1 RTS (out)

2 D+ CLKIN (KBD side)

3 D- DATAIN (KBD side)

4 GND GND GND

5 RX

6 TX

7 VCC VCC VCC

8 CLKOUT (PC side)

9 DATAOUT (PC side)

10 CTS (in)
