Datalogic PowerScan PM9501 Series User Manual

Using the PowerScan™ PM9501
2 PowerScan™ PM9501
Using the PowerScan™ PM9501
The PowerScan™ PM9501 normally functions by capturing
and decoding bar codes. The reader is equipped with an
internal Motionix™ motion-sensing function which acti-
vates the aiming system on device motion. The intelligent
aiming system indicates the field of view which should be
positioned over the bar code:
Table 1. Aiming System
Autoscanning
An autoscan command causes the reader to
scan continuously and to monitor the central
zone of its reading area.
Flash Memory
Flash technology allows you to upgrade the
PowerScan™ PM9501 reader as new symbolo-
gies are supported or as new features become
available.
USA Driver License
Parsing
The reader can be set up to select and output a
subset of data elements from USA Driver
License PDF417 barcodes. This feature can be
enabled using either Datalogic Aladdin™ or the
barcodes in the USA Driver License Parsing
Quick Reference Guide (QRG), available on the
Datalogic website.
MODEL P/N AIMER PATTERN
PM9501/
PM9501-DPM
PM9501-HP

Datalogic PowerScan PM9501 Series Specifications

General

Scanner Type	Handheld
Connectivity	Wireless
Drop Resistance	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Industrial
Storage Temperature	-40 to 70 °C / -40 to 158 °F
IP Rating	IP65
Radio Range	100 m / 328 ft
Radio Frequency	433 MHz; 910 MHz
Decode Capability	1D / 2D
Scanning Technology	Laser or Imager
Interface	RS-232, USB
Supported Barcodes	All standard 1D and 2D barcodes
Resolution	4 mil (1D Codes); 5 mil (2D Codes)
Humidity	5 to 95% (non-condensing)
Drop Specification	2.0 m / 6.6 ft onto concrete
Dimensions	8.3 x 4.3 x 2.9 in
Power Supply	Rechargeable Li-ion battery or USB power
