Datalogic PowerScan PM9501 Series User Manual

Technical Specifications
14 PowerScan™ PM9501
Performance Characteristics
Light Source LED
Roll (Tilt) Tolerance ± 180°
Pitch Tolerance ± 40°
Skew (Yaw) Toler-
ance
± 40°
Print Contrast
Minimum
15% minimum reflectance
ITEM DESCRIPTION
Resolution
PM9501 PM9501-HP
Max resolution 1D
4 mils
Max resolution 2D
7.5 mils
1D 2.5 mil
2D 4 mil
Depth of Field (Typical)
a
a. 13 mils DOF based on EAN. All other 1D codes are Code 39. All labels grade
A,300 lux ambient light, 20°C, label inclination 10°
Symbology Standard Model: High Performance:
Code 39
4 mils: 6-17 cm
20 mils: 4-55 cm
40 mils: 4-85 cm
2.5 mils: 2-6 cm
20 mils: 3-70 cm
40 mils: 3-110 cm
EAN 13 13 mils: 4-48 cm 13 mils: 3-60 cm
PDF-417 10 mils: 2-25 cm 10 mils: 2-30 cm
DataMatrix
7.5 mils: 7-14 cm
10 mils: 4-18 cm
4 mil: 2-6 cm
10 mil: 2-20 cm

Datalogic PowerScan PM9501 Series Specifications

General

Scanner Type	Handheld
Connectivity	Wireless
Drop Resistance	Withstands repeated drops from 2.0 m / 6.6 ft onto concrete
Sealing	IP65
Operating Temperature	-20 to 50 °C / -4 to 122 °F
Type	Industrial
Storage Temperature	-40 to 70 °C / -40 to 158 °F
IP Rating	IP65
Radio Range	100 m / 328 ft
Radio Frequency	433 MHz; 910 MHz
Decode Capability	1D / 2D
Scanning Technology	Laser or Imager
Interface	RS-232, USB
Supported Barcodes	All standard 1D and 2D barcodes
Resolution	4 mil (1D Codes); 5 mil (2D Codes)
Humidity	5 to 95% (non-condensing)
Drop Specification	2.0 m / 6.6 ft onto concrete
Dimensions	8.3 x 4.3 x 2.9 in
Power Supply	Rechargeable Li-ion battery or USB power
