Datalogic QuickScan BC2030 User Manual

Reading Parameters
Quick Reference Guide 29
Numlock
This option specifies the setting of the Numbers Lock (Num-
lock) key while in keyboard wedge interface. This only applies
to alternate key encoding interfaces. It does not apply to USB
keyboard.
Reading Parameters
Point the reader at the target and pull the trigger to enable
the aiming system and the illuminator (red beam) to decode
the barcode label. The aiming system will briefly switch off
during the acquisition time and if no code is decoded will
switch on again before the next acquisition. The illuminator
will remain on until the symbol is decoded.
As you read code symbols, adjust the distance at which you
are holding the reader.
Aiming System
A number of options for customizing control of the Aiming
System are available. See the PRG for more information and
programming bar codes.
ENTER/EXIT PROGRAMMING MODE
Numlock = Numlock key unchanged
Numlock = Numlock key toggled

Datalogic QuickScan BC2030 Specifications

General

Type	Handheld
Battery Type	Lithium-Ion
Operating Temperature	0 to 50 °C / 32 to 122 °F
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	5% to 95% (non-condensing)
Drop Resistance	1.5 m / 5.0 ft
Light Source	LED
Interface	USB
Resolution	4 mil
Supported Barcodes	Code 39, Code 128, QR Code, Data Matrix
