Technical Specifications
Quick Reference Guide 37
User Environment
Operating
Temperature
32° to 122° F (0° to 50° C)
Charging
Temperature
32° to 104° F (0° to 40° C)
Storage
Temperature
-4° to 158° F (-20° to 70° C)
Humidity
Operating: 5% to 90% relative humidity,
non-condensing
Drop Specifications
Scanner withstands 18 drops from 1.5 m
(4.9 feet) to concrete
Ambient Light
Immunity
Up to 100,000 Lux
Contaminants
Spray/rain Dust/
particulates
IEC 529-IP42 (scanner only)
ESD Level 16 KV
Regulatory
Electrical Safety UL 60950, CSA C22.2 No. 60950, IEC 60950
EMI/RFI
Europe; Australia; Russia; USA/CANADA;
Japan; Mexico; South Korea; Brazil; Argen-
tina; China; Singapore; Taiwan
Radio Features
Frequency Range 2400 to 2483.5 MHz
Range (in open air) 25 m
a. It is acceptable to handle this with ULE
b. See "Interface Selection" on page 24 for a listing of available interface sets
by version type.
