Symbologies
148 QuickScan® QD2100
GS1 DataBar Expanded — cont.
GS1 DataBar Expanded Set Length 1
This feature specifies one of the barcode lengths for GS1 DataBar Expanded Length
Control
. Length 1 is the minimum label length if in Variable Length Mode, or the first
fixed length if in
Fixed Length Mode. Length includes the barcode’s data characters on-
ly.
The length can be set from 1 to 74 characters.
Follow these instructions to set this feature:
1. Determine the desired character length (from 1 to 74). Pad the number with leading
zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc.
2. Scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Programming
Mode.
3. Scan the barcode: SELECT GS1 DataBar EXPANDED LENGTH 1 SETTING.
4. Scan the appropriate two digits from the keypad in Appendix E, Keypad, that represent
the length setting which was determined in the steps above. You will hear a two-beep indi-
cation after the last character.
5. Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming
Mode.
This completes the procedure. See Table 19 for some examples of how to set this feature.
Table 19. GS1 DataBar Expanded Length 1 Setting Examples
NOTE
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
STEP ACTION EXAMPLES
1 Desired Setting 01 Character 07 Characters 52 Characters 74 Characters
2 Scan ENTER/EXIT PROGRAMMING MODE
3 Scan SELECT GS1 DataBar EXPANDED LENGTH 1SETTING
4
Scan Two Characters From
Appendix E, Keypad
‘0’ and ‘1’ ‘0’ and ‘7’ ‘5’ and ‘2’ ‘7’ AND ‘4’
5 Scan ENTER/EXIT PROGRAMMING MODE
