Datalogic QuickScan i QD2100 Product Reference Guide

Product Reference Guide
302
IBM31xx 102-key Table 45. Scancode Set When Control Character is 00 or 01
X0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF
0x
NULL C(S)+@
SOH C(S)+A
STX C(S)+B
ETX C(S)+C
EOT C+D
ENQ C(S)+E
ACK C(S)+F
BEL C(S)+G
BS C(S)+H
HT TAB
LF C(S)+J
VT C(S)+K
FF C(S)+L
CR Enter
SO C(S)+N
SI C(S)+O
1x
DLE C(S)+P
DC1 C(S)+Q
DC2 C(S)+R
DC3 C(S)+S
DC4 C(S)+T
NAK C(S)+U
SYN C(S)+V
ETB C(S)+W
CAN C(S)+X
EM C(S)+Y
SUB C(S)+Z
ESC Esc
FS C(S)+\
GS C+]
RS C(S)+^
US C(S)+_
2x
Space ! “ # $ % & ‘ ( ) * + , - . /
3x
0123456789: ;<=>?
4x
@AB CD E F GH I J K LMNO
5x
P QRSTUVWXYZ [ \ ] ^ _
6x
‘ a Bcde fgh i j k lmno
7x
pqRs tuvwxyz{ | } Del
8x
ShÈ ShÇ Ins Ent
(keyp)
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11
9x
F12 Enter Reset Insert Delete Field - Field
+
Enter paddle
Printl ArÈ ArÇ AlÈ AlÇ ClÈ ClÇ CrÈ
Ax
CrÇ

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
