Datalogic QuickScan i QD2100 Product Reference Guide

Product Reference Guide
296
Interface Type PC AT PS/2 or USB-Keyboard Table 39. Scancode Set When Control Character is 00 or 01
Extended characters (sky blue) are sent via dedicated keys (when available in the selected country mode) or by an Alt Mode sequence.
x0
x1 x2 x3 x4 x5 X6 x7 x8 x9 xA xB xC xD xE xF
0x
NULL C(S)+@
SOH C(S)+A
STX C(S)+B
ETX C(S)+C
EOT C+D
ENQ C(S)+E
ACK C(S)+F
BEL C(S)+G
BS C(S)+H
HT TAB
LF C(S)+J
VT C(S)+K
FF C(S)+L
CR Enter
SO C(S)+N
SI C(S)+O
1x
DLE C(S)+P
DC1 C(S)+Q
DC2 C(S)+R
DC3 C(S)+S
DC4 C(S)+T
NAK C(S)+U
SYN C(S)+V
ETB C(S)+W
CAN C(S)+X
EM C(S)+Y
SUB C(S)+Z
ESC Esc
FS C(S)+\
GS C+]
RS C(S)+^
US C(S)+_
2x
SP ! " # $ % & ' ( ) * + , - . /
3x
0123456789: ;<=>?
4x
@AB CD E F GH I J K LMNO
5x
PQRSTUVWXYZ [ \ ] ^ _
6x
`abcdefghijklmno
7x
pqr s tuvwxyz{ | }~Del
8x
_
ShÈ ShÇ
Ins Ent
(keyp)
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10 F11
9x
F12 Home End Pg Up Pg
Dwn
Ç È Å Æ ArÈ ArÇ AlÈ Al Ç ClÈ Cl Ç CrÈ
Ax
CrÇ
_ ‘ ƒ „ …
† ‡
ˆ ‰ Š ‹ ĝ ‹ Œ _
Bx
° ± ² ³ ´ μ ¶ · ¸ ¹ º » ¼ ½ ¾ ¿
Cx
À Á Â Ã Ä Å Æ Ç È É Ê Ë Ì Í Î Ï
Dx
Ð _ Ò Ó Ô Õ Ö × Ø Ù Ú Û Ü Ý Þ ß
Ex
à á â ã ä å æ ç è é ê ë ì í î ï
Fx
ð ñ ò ó ô õ ö ÷ ø ù ú û ü ý þ ÿ

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
