Datalogic QuickScan i QD2100 Product Reference Guide

Global Prefix/Suffix
Product Reference Guide 91
6. Scan the ENTER/EXIT barcode once again to exit Programming Mode.
7. The resulting message string would appear as follows:
Scanned barcode data:12345
Resulting message string output: $12345
This option sets up to 20 characters each from the set of ASCII characters or any hex val-
ue from 00 to FF. To configure this feature, scan the ENTER/EXIT barcode to place the
unit in Programming Mode, then the “Set Global Prefix” or “Set Global Suffix,” barcode
followed by the digits (in hex) from the Alphanumeric characters in Appendix E, Key-
pad
representing your desired character(s). If less than the expected string of 20 charac-
ters are selected, scan the ENTER/EXIT barcode to terminate the string. Reference the
section,
Example: Setting a Prefix on page 90, for more information. Exit program-
ming mode by scanning the ENTER/EXIT barcode once again.
ENTER/EXIT PROGRAMMING MODE
Set Global Prefix
Set Global Suffix
Make a mistake? Scan the CANCEL barcode to abort and not
save the entry string. You can then start again at the beginning.
CANCEL
DEFAULT
No Global Prefix
Global Suffix = 0x0D (CR)

Datalogic QuickScan i QD2100 Specifications

General

Scan speed	8 sec/page
Wavelength	610 nm
Tilt angle range	-65 - 65 °
Decoding standards	1D / GS1 DataBar China Post GS1 DataBar Expanded/ Stacked/ Stacked Omnidirectional
Dimensions (WxDxH)	170 x 66 x 71 mm
Standard interfaces	RS-232, USB, Keyboard wedge
Input voltage	5 V
Power consumption	340 mA
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Weight	121.9 g
