Datalogic QuickScan QD2590

Setting Up the Reader
4 QUICKSCAN™ QD2590
SETTING UP THE READER
Follow the steps below to connect and get your reader up
and communicating with its host.
1. Connect the Cable to the reader and the Host as
shown below.
2. Configure the Interface (see page 9).
3. Program the Reader starting on page 21 (optional,
as needed).
Connecting to the Host Interface
USB
WEDGE
RS-232
