Datalogic Touch 90 pro Quick Reference

USING TOUCH™SERIES READERS
Touch™readers scan barcodes on contact. All models have a
hardware trigger button which by default must be pressed to
read a code. After configuring the reader interface type, the
software trigger parameter (available in this manual) can be
selected so that the reader operates like a model without
trigger.
Code scanning is performed along an imaginary line passing
across the reading window. This imaginary line must pass
through the entire code.
Successful scanning is obtained by keeping the handle of the
reader parallel with respect to the code surface, see the figure
above.
CONNECTIONS
RS232
With the RS232 cable, this accessory device is intended to be
supplied by a UL Listed Direct Plug-in Power Unit marked
"Class 2", rated 5 V, minimum 150 mA
.
scanning line
trigger button

Datalogic Touch 90 pro Specifications

General

Scan speed	256 sec/page
Decoding standards	2/5 family, Code 39, Code 32, Code CIP 39, Code 128, EAN128, EAN/UPC, ISBN/ISSN, CODABAR, Code 93, ISBT128, MSI, Plessey, Telepen, Delta IBM, Code 11, Code 49, Code 16K, GS1 Databar
Standard interfaces	USB, RS-232
Input voltage	5 V
Power consumption	150 mA
Dimensions (WxDxH)	175 x 100 x 80 mm

Weight and Dimensions

Weight	195 g
