ISO MAX V Manual – v. 1.2 – july 2012 13
7. Open the “Ports” drilldown menu and check the COM number assigned to the USB serial port.
Note: You can use Hyperterminal to test the connection.
Please refer to the section 4.6.
4.3 USB driver installation guide for MAC OS
1. Insert the CD in the computer.
2. Click on the CD volume.
3. Double click on the ”ISO MAX.HTML”.
4. Double click on the MAC OSX or OS8/9 (according to your operating system).
5. Install the extracted data to the System Folder / Extension Folder.
Please refer to your Operating System manual.
4.4 RS-232 installation guide
The RS-232 interface version does not require any software installation. Plug in the RS-232
cable between your reader and the PC. Then refer to chapter 4.6.
4.5 Bluetooth installation guide for Windows XP OS
In order to connect the ISO MAX V reader to a host PC through Bluetooth, a PC equipped with
Bluetooth hardware and the ISO MAX V equipped with the Bluetooth module are needed.
4.5.1 Configure ISO MAX V for the Bluetooth connection
During the Bluetooth discovery process done by the PC, it is important that the ISO MAX V
reader is ON. It is therefore advisable to set the shutdown timeout to 5 minutes (Menu -> Setup
-> Shutdown timeout). Moreover, press the LEFT and RIGHT arrow button in order to reset the
shutdown timeout.
Under the Bluetooth menu, switch on the feature Act as a Server while switch off Act as a
Client.
4.5.2 Search for and recognize the ISO MAX V by a host PC
From the control panel choose Bluetooth Device. The following dialog window appears.
