Datapath Fx4 User Manual

Specications
22
Chapter 11 - Specications
Dimensions W 316mm x D 172mm x H 42mm (1.86kg).
Operating Temperature 0 - 35 DegC / 32 - 96 DegF.
Power Requirements IEC switched and fused mains connector 100-240V, 50/60Hx / 30W.
Video Input Connections
1 x DisplayPort 1.2 (2160p/60 or equivalent up to 616MPixels/s).
2 x HDMI 1.4 (2160p/30 or equivalent up to 297 MP/s).
Video Output Connections
HDMI Model:
4 x HDMI 1.4 (1080p/60 or equivalent up to 165 MP/s).
DisplayPort Model:
4 x DisplayPort 1.1 (1080p/60 or equivalent up to 165MP/s).
Loop-through (both models).
DisplayPort1.2 (locked to selected video input resolution).
Input Surface 8k x 8k maximum.
Genlock Input
Analogue black-burst on dedicated BNC connector.
Any video input (HDMI 1, HDMI 2, DisplayPort).
Control Interfaces
Dual 100BaseT Ethernet ports with in built managed switch.
USB 2.0 Type B connector (full speed operation).
Firmware Support Updates supported via USB and Ethernet connection
Storage Temperature -20 to 70 DegC / -4 to 158 DegF
Relative Humidity 5% - 90% non-condensing
Warranty 3 years
W = 316mm
H = 42mm
D = 172mm

Datapath Fx4 Specifications

General

Inputs	1 x DisplayPort 1.2, 2 x HDMI 1.4
Maximum Input Resolution	4096x2160 @60Hz
Bezel Correction	Yes
HDCP	Yes
Genlock	Yes
Scalers	Yes, per output
Supported Platforms	Windows, Linux
Resolution Support	Up to 4K
Maximum Output Resolution	4096x2160 @ 60Hz
Rotation	Yes
Audio	Audio pass-through via DisplayPort and HDMI
Control	Ethernet
Power Supply	100-240V AC, 50-60Hz
Video Processing	Real-time
