Datapath Fx4 User Manual

Index
25
Chapter 13 - Index
A
Allocating inputs 16
Auto-cong Fx4 16
B
Background Image 12
Bit Rate 14
C
Cable Lengths 14
Cables 5
Cable Type 14
Cable Lock 13
Certication 21
Class A Declaration of Conformity 21
Compliances 21
Connecting a House Sync Cable 13
Connecting an Input 15
Connecting Outputs 15
Connecting the Out Loop 14
Control Interfaces 22
D
Devices 12
DHCP 18
Dimensions 22
Display Screens Turn Red 19
Disposal 21
F
FCC Rules 21
Features 7
Firmware Support 22
Fonts and Symbols 4
G
Gateway 18
Genlock Input 22
H
HDMI Cable Lock 13
Help Files 12
High Bit Rate 14
I
Initial Inspection 5, 6
Inputs 8, 12
Input Surface 22
Install the Wall Designer Software 11
Introduction 4
IP address 18
L
LAN Port 17
LEDs 8
M
Maintenance 5
Manufacturer Warranty 23
Monitor Outputs 9
Monitors 12
Mounting screws 9
N
Network Settings 18
Network Timing Out 19
O
Operating Temperature 22
Operation Indicators 8
Operation Modes 11
Out Loop 17
Overview 7
P
Power Requirements 22
Power Supply 5
Product End of Life 21

Datapath Fx4 Specifications

General

Inputs	1 x DisplayPort 1.2, 2 x HDMI 1.4
Maximum Input Resolution	4096x2160 @60Hz
Bezel Correction	Yes
HDCP	Yes
Genlock	Yes
Scalers	Yes, per output
Supported Platforms	Windows, Linux
Resolution Support	Up to 4K
Maximum Output Resolution	4096x2160 @ 60Hz
Rotation	Yes
Audio	Audio pass-through via DisplayPort and HDMI
Control	Ethernet
Power Supply	100-240V AC, 50-60Hz
Video Processing	Real-time
