LED INDICATORS
For more information, please refer to “LED INDICATORS” under Glossary
section.
Power
Disk 4
Disk 3
Disk 2
Disk 1
RAID Alert
Green: On / Off
Red: On / Blink / Flash
White: On / Flash
