Place The HDD SmartGuider Kit Inside The RAID System
9. Hold the HDD SmartGuider Kit with its metal cover side facing you and the
Handle attached in the upward position.
If the HDD SmartGuider Kit is inserted on its reverse side, the SmartGuider
System would not be able to align and the HDD SmartGuider Kit cannot be
inserted.
10. Align the Handle with the guide rails and slide the HDD SmartGuider Kit into
the indicated Disk Slot. Firmly push downward until a “thump” sound is heard.
Repeat the same procedures for rest of the HDD SmartGuider Kit(s).
In most cases, you would need to firmly push the HDD SmartGuider Kit to
a close until a “thump” sound is heard.
