Datavideo TLM-170F User Manual

8
2. Connections and Controls
Front Panel
Buttons
Descriptions
Power ON/OFF
This button powers the monitor ON/OFF. The main power switch
is located at the rear of the TLM-170F.
SDI Button
Press once to enable the SDI video source on the monitor screen.
You can connect the loop thru port (see Rear Panel) to a monitor
to view the activated input video source.
As the SDI video source is activated, the button LED will be turned
ON.
Dual Color Tally Light
Video Source
MENU
Activation
Return/EXIT
Headphone
Audio Volume
Control
Power
ON/OFF
Shortcut Keys
