22
• If the controls are untouched for ~ 30 seconds, the menu will revert back to normal display;
• Using the
Menu up button and
Menu down button scroll through to LEVEL;
• Use the
Menu up button and
Menu down button to change the setting to Y;
• Press the
Enter button to save settings and return to the HOME SCREEN;
• Now restart automatic operation by pressing
Automatic on / manual off button.
Once the menu has been changed to acknowledge the external float, the external float can be wired into
the DynaDrive controller. The normally open terminals will not trigger fault/alarm/pause conditions. When
the terminals are closed circuit, the DynaDrive operates normally. Davey recommends a float switch cable
no longer than 3m (10 feet), when using 2 x 0.25mm (24 AWG) cable. If the switch overrides DynaDrive to
pause, the DynaDrive display will show a flashing
Fault LED.
The
Automatic LED will also flash on the control display, see figure 7.9.
Figure 7.9
P/ N :16115 -1 B
A 1 0
dry run
Once the switch is reversed, for example the rainwater tank filling again, the DynaDrive will restart and the
display will return to normal.
