3KP64 - 3.8
3000PLUS WITH 5D64 INSTRUCTION MANUAL V. SB.2
Daytronic Corporation
2211 Arbor Blvd. Dayton, OH 45439 • (800) 668-4745
Tel: (937) 293-2566 • Fax: (937) 293-2586 • www.daytronic.com
SETUP STAGE 2: INPUT RANGE INFORMATION
(cont’d)
When the
3000PLUS
displays this . . . Do this . . .
NOTE: The FULL-SCALE OUTPUT (“FSU”) parameter is critical for proper
module CALIBRATION (Stage 4, below). It will also determine the “count”
value for the 3000PLUS display’s least significant digit (see Section 1.D).
2.h. Then press
to proceed to
Setup Stage 3 (next page).
To Next Page
