3KP64 - 3.31
3000PLUS WITH 5D64 INSTRUCTION MANUAL V. SB.2
Daytronic Corporation
2211 Arbor Blvd. Dayton, OH 45439 • (800) 668-4745
Tel: (937) 293-2566 • Fax: (937) 293-2586 • www.daytronic.com
SETUP STAGE 5: LIMITS
(cont’d)
When the
3000PLUS
displays this . . . Do this . . .
Use
and
as explained in Section 3.A to adjust the displayed number until the
desired high limit hysteresis value is obtained (expressed in measurement
units). Enter a value of zero (“0,” “0.0,” etc.) to indicate no deadband.
NOTE: You will not be allowed to enter a negative number, or a number
that is greater than the
difference between the existing HIGH LIMIT and
LOW LIMIT values.
Then press
to proceed to
Setup Stage 6 (next page).
To Next Page
